Every span in LumiqTrace has a span_kind field that describes the type of operation it represents. The span kind controls how the span is rendered in the flame graph, which icon it gets in the trace detail view, and how it is counted in agent analytics. Understanding span kinds is essential for building multi-agent systems that look correct in the dashboard.

​
Complete span kind reference

llm

A direct call to a language model API. This is the most common span kind. Set automatically by all provider wrappers (wrapOpenAI, wrapAnthropic, wrapGoogle, etc.).

agent

The execution scope of a single agent. Created by withAgent() in TypeScript, with_agent() in Python, and the ADK/LangChain integrations automatically. Contains all child spans produced during the agent’s run.

tool

A single tool or function invocation by an agent. Created by agent.traceTool() or automatically by the LangChain and ADK integrations when a tool is called.

planning

A planning step created by agent.logPlan(). Records the steps the agent intends to take before executing them. Useful for debugging agent reasoning.

handoff

An agent-to-agent delegation. Created by agent.delegateTo() or automatically by multi-agent frameworks. Links to the target agent span in the trace tree.

retriever

A document retrieval operation (vector search, keyword search, hybrid). Set on manual spans in RAG pipelines via startSpan({ span_kind: "retriever" }) or automatically by the LangChain retriever handler.

guardrail

A guardrail check execution. Set automatically when the SDK’s guardrail client makes a check request. Shows pre/post phase, action taken (allowed/blocked/redacted), and latency.

general

A generic custom operation that doesn’t fit another category. The default for manually created spans that don’t specify a span_kind.

​
Flame graph rendering

Each span kind is rendered differently in the trace flame graph:
Span kindColor (dark theme)IconIndentation
llmCyan (#00d4ff)CPU chipBased on nesting depth
agentPurpleBotCreates a group header
toolAmberWrenchChild of agent span
planningSlateListChild of agent span
handoffBlueArrowChild of agent span
retrieverGreenSearchChild of LLM or general span
guardrailOrangeShieldBefore/after LLM span
generalGrayCircleBased on nesting depth

​
Setting span kind manually

When creating a manual span with startSpan(), set the span_kind explicitly:
import { startSpan } from "@lumiqtrace/sdk";

// Retrieval span
const { span } = startSpan({
  name: "vector-search",
  span_kind: "retriever",
  provider: "custom",
});

try {
  const docs = await vectorStore.search(query, { topK: 5 });
  await span.end({ status: "success" });
  return docs;
} catch (err) {
  await span.end({ status: "error", error_message: String(err) });
  throw err;
}

​
How span kinds appear in the agent registry

The Agents section of the dashboard uses span kinds to build its agent registry:
  • Spans with span_kind: "agent" appear as agent nodes
  • Their parent_span_id is used to build the coordinator-specialist hierarchy
  • tool spans are aggregated under their parent agent to build the tool inventory
  • handoff spans are used to draw delegation arrows between agents
To have your agent appear correctly in the registry, always set agentRole: "coordinator" on orchestrators and agentRole: "specialist" on sub-agents.
Agent registry view in LumiqTrace showing coordinator and specialist hierarchy

​
SpanKind in the event schema

The span_kind field is part of the LumiqEvent schema sent to the ingest endpoint. When building a custom integration (not using an SDK wrapper), include it explicitly:
{
  "event_id": "...",
  "trace_id": "...",
  "span_id": "...",
  "span_kind": "tool",
  "provider": "custom",
  "model": "custom",
  "operation": "tool-call",
  ...
}
Valid values: "llm", "agent", "tool", "planning", "handoff", "retriever", "guardrail", "general".
